OGSolarStore

DC Adjustable Power Supply 30~120Vdc 3~10A

£78.00 GBP
£94.00 GBP £78.00 GBP
✔️ In Stock in Michigan, USA
Tax included.
Color

There are 3 product variants:

  1. 30V max at 10A
  2. 60V max at 5A
  3. 120V max at 3A

Product Specifications

KPS series DC power supply is a single output, high-precision dual display switching DC power supply. The machine has complete operation protection function, high efficiency, low ripple, high stability and small volume. Current limiting protection protects the KPS power supply and load from accidental damage. KPS series power supply has temperature control circuit and low intelligent heat dissipation noise
  • Digital display: three LED digital tube double display.
  • 3-digit display 0.1 V/0.01 A
  • Display accuracy: ± 1% + 2 digits.
  • Input voltage: AC 230V / 115V± 10%; 50Hz / 60Hz.
  • Output voltage stabilizing value: 0-30/0-60V/0-120 continuously adjustable.
  • Output constant current value: 0-10A/0-5A/0-3A continuously adjustable.
  • Ripple voltage: VPP ≤ 1%
  • Overall efficiency: ≥ 89%.
  • Working temperature: (- 10 ～ 45) ℃.
  • Storage temperature: (- 20 ～ 60) ℃.
  • Relative humidity: 90% (40 ± 5 ℃).

Features include:

  1. AC 110V and 220V compatible.
  2. Low ripple, small size and light weight
  3. Double LED display of voltage and current, high precision
  4. Stable voltage, limited current and simple operation
  5. Double voltage input, convenient selection
  6. Temperature controlled fan for heat dissipation, low noise and long service life
  7. Output Voltage ranges from 0 to rating voltage with continuous adjustment.
  8. Output Current ranges from 0 to rating current with continuous adjustment
  9. Short circuit protection function, short circuit stop output, overload protection, over temperature protection.

Packaging Includes:

  • 1x DC power supply
  • 1x power cord (EU,US,UK,AU)
  • 1x Test line
  • 1x Instructions
