Product overview
Sodium-ion · 18650 · NFPP · Model 18650H-D
Sodium-ion 18650 battery cells with an NFPP (sodium iron phosphate) cathode, sold in 4-packs for DIY 12V, 24V and 48V packs. Each cell is rated 850 mAh and 40C (34 A) continuous, and discharges down to −40 °C. Charge to 3.65 V per cell (3.70 V max) and cut off at 2.0 V; a sodium-set BMS and charger are required. The full datasheet, our bench test and BMS setpoints for 4S, 8S and 16S packs are on this page.
- OGS part
- SIB-18650-NFPP-04
- Capacity
- 850 mAhrated at 0.2C · 800 min [1]
- Nominal
- 3.0 Vwindow 1.5 to 3.7 V [1]
- Continuous
- 34 A40C · 60C (51 A) for 5 s [1]
- Charge
- 3.70 V maxCC-CV · 0.5C standard · 3.30 V below 0 °C [1]
- Cycle life
- 1,200 cycto 85 % · 1C charge and discharge, 25 °C [1]
- Discharge temp
- −40 to 70 °Ccharge −10 to 60 °C [1]
- Build
- Flat top · Unprotected · Bare cell · Ships at ≥ 2.0 V
Dimensions mm, drawn to scale
Mass 36.0 ±0.5 g
Flat top, no protection circuit. Dimensions and tolerances from the datasheet [1].
Why this cell
Built for current
40C34 A continuous, 60C (51 A) for 5 s [1]
Still gives ≥ 70 % of its capacity at a 40C load, and ≥ 90 % at 10C [1]. Four in parallel handle about 136 A continuous on paper.
Works in the cold
−40 °Cdischarge, ≥ 60 % capacity at −40 °C [1]
≥ 85 % at −20 °C. Charging is the limit: none below −10 °C, and 0.1C to 3.30 V max from −10 to 0 °C [1]. If your BMS can't lower both, block charging below 0 °C.
Long life
1,200cycles to 85 % capacity [1]
At 1C charge and discharge, about 3 years at one full cycle a day, still holding 85 %. Shallower, slower cycles go further.
Common applications
- Cold-climate 12V packs for vans, truck campers and ice-fishing shelters
- High-current packs: power tools, jump starters and robotics
- LoRa and Meshtastic solar nodes and remote sensors that stay out all winter
- Lab and university bench testing of sodium-ion chemistry
- Small DC backup for routers and ham radio
- Prototype packs for e-bikes and scooters
Specifications every value names its source
| Attribute | Value | Condition and source |
|---|---|---|
| Rated · manufacturercopied from the datasheet [1] | ||
| Chemistry | Sodium-ion, NFPP (sodium iron pyrophosphate) | cathode stated by the supplier [2]; the datasheet does not name it |
| Capacity, rated | 850 mAh | 0.2C, 1.5 to 3.7 V [1] |
| Capacity, minimum | 800 mAh | same conditions [1] |
| Nominal voltage | 3.0 V | [1] |
| Charge voltage, max | 3.70 V | CC-CV, 0 to 60 °C. 3.30 V max from −10 to 0 °C [1] |
| Float voltage, max | 3.70 V | [1] |
| Discharge cut-off | 1.5 V | end of discharge [1] |
| Standard charge | 0.5C (0.425 A) | CC-CV to 3.7 V, stop at 0.05C (43 mA), 25 ±2 °C [1] |
| Max charge current | 5C (4.25 A) | 25 to 35 °C, from the temperature table [1]. Table 3 also lists 7C to 3.7 V, rated for 300 cycles; we show the lower value |
| Max continuous discharge | 40C (34 A) | 20 to 45 °C allows 35C continuous in the temperature table [1] |
| Max pulse discharge | 60C (51 A) | 5 seconds or less [1] |
| Internal resistance | ≤ 16 mΩ | AC 1 kHz after a standard charge [1] |
| As shipped | ≥ 2.0 V | shipment voltage [1] |
| Performance · manufacturer testtest method in the datasheet, §4.3 [1] | ||
| Cycle life | ≥ 85 % at 1,200 | 1C charge to 3.7 V (0.05C stop), 1C discharge to 1.5 V, 25 °C [1] |
| Cycle life, high rate | ≥ 70 % at 800 | 5C charge and discharge. 3C: 1,000 cycles, 7C: 500 cycles, same 70 % end point [1] |
| Rate capability | ≥ 70 % at 40C | ≥ 90 % at 10C, ≥ 85 % at 20C, ≥ 80 % at 30C, 25 °C [1] |
| Capacity at −20 °C | ≥ 85 % | 8 h soak, then 0.5C to 1.5 V [1] |
| Capacity at −40 °C | ≥ 60 % | 8 h soak, then 0.5C to 1.5 V [1] |
| Capacity at −20 °C, 10C load | ≥ 80 % | ≥ 85 % at −10 °C, 8 h soak, 10C to 1.5 V [1] |
| Capacity at 55 °C | ≥ 95 % | 2 h soak, then 0.5C to 1.5 V [1] |
| Charge retention, 28 days | ≥ 90 % | full charge, 25 °C. ≥ 95 % recovered after a recharge [1] |
| Charge retention, 7 days at 60 °C | ≥ 85 % | ≥ 90 % recovered [1] |
| Temperaturemeasured at the cell surface [1] | ||
| Charge, −10 to 0 °C | 0.1C max | to 3.30 V max [1] |
| Charge, 0 to 10 °C | 0.2C max | to 3.70 V [1] |
| Charge, 10 to 20 °C | 0.5C max | [1] |
| Charge, 20 to 25 °C | 1C max | [1] |
| Charge, 25 to 35 °C | 5C max | [1] |
| Charge, 35 to 60 °C | 1C max | [1] |
| Discharge | −40 to 70 °C | 5C max to −30 °C, 10C to −20 °C, 20C to 0 °C, 30C to 20 °C, 35C to 45 °C, 5C to 60 °C, 1C to 70 °C [1] |
| Storage | −10 to 35 °C | up to 6 months (−10 to 40 °C under 1 month), ≤ 65 % RH, at 2.0 to 3.2 V. Recharge after 6 months [1] |
| Calculatedarithmetic on [1] and [3], shown so you can check it | ||
| Energy per cell | 2.55 Wh | 0.85 Ah × 3.0 V |
| Energy density, gravimetric | ≈ 71 Wh/kg | 2.55 Wh ÷ 36.0 g |
| Energy density, volumetric | ≈ 146 Wh/L | 2.55 Wh ÷ 17.4 cm³ (cylinder, 18.41 × 65.5 mm) |
| Standard discharge | 0.5C (0.425 A) | the rate the datasheet uses for its capacity and temperature tests [1] |
| Usable capacity, typical inverter window | ≈ 74 to 78 % | 12V inverters cut off near 10.0 to 10.5 V, or 2.5 to 2.6 V per cell. Share of the capacity above that, at 0.5C [3] |
| Energy per 4-pack | 10.2 Wh | 4 × 2.55 Wh |
OGS bench test our own charge and discharge
These results are from the previous batch of this cell (900 mAh, 20C). Our test of the current 850 mAh 18650H-D cell is next and will replace them.

- Capacity delivered
- 851 mAh 95 % of the 900 mAh rating, at 0.5C
- Charge back out
- 100 % 851 mAh out of 850 mAh put in
- Energy back out
- 89 % 2.34 Wh out of 2.63 Wh in, test-lead loss included
One cell, room temperature, charged to 3.70 V and discharged at 0.45 A (0.5C) to 1.50 V. Full method in the test report.
BMS and charger setpoints
Per-cell values from the datasheet [1] and our bench test [3], multiplied out for common packs. For the 18650H-D cell; the 900 mAh batch shares the same voltages.
| Setpoint | Per cell | 4S | 8S | 16S |
|---|---|---|---|---|
| BMS over-voltagemaximum charge voltage [1] | 3.7 V | 14.8 V | 29.6 V | 59.2 V |
| Charge voltage (CV)charger setpoint, 0.05 V under the limit. Our sodium chargers ship set to this | 3.65 V | 14.6 V | 29.2 V | 58.4 V |
| Nominal[1] | 3.0 V | 12.0 V | 24.0 V | 48.0 V |
| Low cut-off, workingkeeps about 95 % of the capacity [3]. Use 2.5 V if your inverter needs it; that gives up about a fifth | 2.0 V | 8.0 V | 16.0 V | 32.0 V |
| BMS under-voltageabsolute floor [1] | 1.5 V | 6.0 V | 12.0 V | 24.0 V |
Batch history
Current ratings and cold-charge rules differ by batch. Use the row that matches the cells you have; the 900 mAh batch must not be charged below 0 °C. Not sure which you have? Send us your order number.
Works with this cell parts we sell that are set up for it
BMSpre-programmed for sodium
Chargersset to 3.65 V per cell for this cell
Pack build18650 format
Testcheck cells before you build
Questions builders ask
What BMS do I need for NFPP sodium-ion 18650 cells?
One set to NFPP voltages: over-voltage 3.70 V and a discharge cut-off near 2.0 V per cell, with 1.5 V as the absolute floor. Our 12V, 24V and 48V sodium BMS ship pre-programmed for this cell; pick NFPP and put the cell in your order note.
Can I charge NFPP sodium-ion cells below freezing?
Yes, slowly, down to −10 °C: 0.1C max and 3.30 V per cell max from −10 to 0 °C. Do not charge below −10 °C. If your BMS can't lower both current and voltage with temperature, block charging below 0 °C.
Will a 4S NFPP pack work with my 12V inverter?
Usually, but check the inverter's low-voltage cut-off. A 4S pack runs from 14.6 V full (3.65 V per cell) down to 8.0 V (2.0 V per cell). At a 10.0 to 10.5 V cut-off you use about three quarters of the capacity; at 8.0 V you use about 95 %.
NFPP or layered oxide sodium-ion cells?
NFPP handles far more current (40C against 15C), costs a little less and has a flatter voltage curve. Layered oxide holds more energy per cell (1,100 against 850 mAh). Our NFPP vs layered oxide post compares them in detail.
Can I use an LFP or lithium-ion charger?
Never a lithium-ion charger: it charges to 4.2 V per cell, far past this cell's 3.70 V limit. An LFP charger set to exactly 3.65 V per cell (14.6 V for 4S) matches the charge voltage, but check it has no boost or equalize stage above that. Our sodium chargers ship set to 3.65 V per cell.
Related reading
- Sodium-ion pack mathSeries count, voltage window and BMS settings for 12 V to 72 V packs
- Bench test report v1Our discharge curves: NFPP, layered oxide and LFP
- NFPP 18650 cell reviewOur first look at this chemistry
- NFPP vs layered oxideWhich sodium chemistry fits your build
- How to spot weld 18650 cellsNickel strip, weld settings and insulator rings
Sources
- [1] Manufacturer specification for the 18650H-D cell, revision A1, 2025-12-01, 12 pages. Linked under Downloads.
- [2] Supplier listing for this cell. It states an NFPP (sodium iron pyrophosphate) cathode. The datasheet does not name the cathode.
- [3] OGS bench test report v1 (previous 900 mAh NFPP batch, 0.45 A, room temperature). A recommendation, not a manufacturer rating.
